Compressor Coltri MCH6 Gasoline 200Bar
Compressor Coltri MCH6 Gasoline 200Bar
CHARACTERISTICS
Charging rate:
80 L/min - 4,8 m³/h - 2,8 CFM
Filling time cylinder 10 L - 0-200 Bar:
25 min
Working pressure:
300 Bar / 4300 Psi
Driven by:
Single-phase electric motor with centrifugal switch
Rpm pumping unit:
2240
Power:
2,2 Kw
Full load Amp:
*14A (230V-50/60Hz) **29A (115V-60Hz)
Dimensions:
height 35cm/13.7", width 65cm/25.5", depth 39cm/15.3"
Dry weight:
39,5 Kg / 87 lbs
Noise pressure:
81,7 dB
Number of stages and cylinders:
4
Lubricating oil capacity:
300 cc (0,3 L) / 10 FL. OZ.
Lubricant:
Coltri Oil CE 750
CHARACTERISTICS
Charging rate: 100 L/min - 6 m³/h - 3,5 CFM
Filling time cylinder 10 L - 0-200 Bar: 20 min
Working pressure: 225 Bar / 3300 Psi
Rpm pumping unit: 2800
Certified CARB III EPA2-EURO2
Power: 3,6 Kw / 5,5 HP @ 3600 rpm
Fuel: Unleaded petrol
Fuel tank capacity: 3,6 L / 3.8 quarts
Fuel consuption: 0,987 L/h - 1.04 quarts/hour
Dimensions:
height 35cm/13.7", width 78cm/30.7", depth 32cm/12.5"
Dry weight: 37 Kg / 81.5 lbs
Noise power: 100,5 LWA
Noise pressure: 80,5 dB
Number of stages and cylinders: 4
Lubricating oil capacity: 300 cc (0,3 L) / 10 FL. OZ.
Lubricant: Coltri Oil CE 750
Frame: Powder coated steel
Oil/mosture separator:
After last stage with vortex generator
Filtration:
Filter cartridge activated carbon and molecular sieve
Safety valve:
On the separator housing 225-300-330 Bar
Interstage coolers and after coolers:
Stainless steel
Suction filter: 2 micron paper
Breathing air: EN 12021 CGA E
